ASTM A537 Class 1 normalized pressure vessel steel plate
ASTM A537 Class 1 is a normalized, heat-treated carbon-manganese-silicon steel plate designed for pressure vessel service. It offers higher yield and tensile strength compared to standard ASTM A516 grades. The material is killed steel with fine austenitic grain size. It is ideal for use in pressurized service in boilers and pressure vessels where toughness and strength are required.
ASTM: A537 CL1GB: 15CrMoR / 14Cr1MoR (Similar low alloy)JIS: SBV41
MaterialASTM A537 / ASTM A20/A20M
Thickness5-100 mm
Width1000-3000 mm
Length6000-12000 mm
MOQ1 Ton
Lead Time15-25 days
PortShanghai / Tianjin / Qingdao
Response within 24 hours
In Stock — Ready to Ship
| Material Grade | ASTM A537 / ASTM A20/A20M | Standard | ASTM A537 / ASTM A20/A20M |
| Thickness Range | 5-100 mm | Width Range | 1000-3000 mm |
| Length Range | 6000-12000 mm | MOQ | 1 Ton |
| Lead Time | 15-25 days | Port of Shipment | Shanghai / Tianjin / Qingdao |
| C | ≤0.24 | Si | 0.13-0.55 |
| Mn | 0.92-1.72 | P | ≤0.035 |
| S | ≤0.035 | Cu | ≤0.38 |
| Ni | ≤0.28 | Cr | ≤0.29 |
| Mo | ≤0.09 | Yield Strength (≤65mm) | ≥345 MPa |
| Tensile Strength | 485-620 MPa | Elongation | ≥22% |
