H-13 Tool Steel
H-13 is a chromium-molybdenum-vanadium hot work tool steel known for high hardenability, excellent toughness, and resistance to thermal fatigue and abrasion. It offers good machinability, weldability, and ductility, making it ideal for high-temperature applications such as die casting and extrusion.
ASTM: H13JIS: SKD61GB: 4Cr5MoSiV1DIN: 1.2344
MaterialAISI H13 / JIS SKD61 / GB 4Cr5MoSiV1 / DIN 1.2344
ThicknessAvailable in plates, sheets, and blocks
WidthCustomizable
LengthCustomizable
MOQ1 Ton
Lead Time7-15 days
PortShanghai / Tianjin
Response within 24 hours
In Stock — Ready to Ship
| Material Grade | AISI H13 / JIS SKD61 / GB 4Cr5MoSiV1 / DIN 1.2344 | Standard | AISI H13 / JIS SKD61 / GB 4Cr5MoSiV1 / DIN 1.2344 |
| Thickness Range | Available in plates, sheets, and blocks | Width Range | Customizable |
| Length Range | Customizable | MOQ | 1 Ton |
| Lead Time | 7-15 days | Port of Shipment | Shanghai / Tianjin |
| C | 0.32-0.45 | Si | 0.80-1.20 |
| Mn | 0.20-0.50 | P | ≤0.030 |
| S | ≤0.030 | Cr | 4.75-5.50 |
| Mo | 1.10-1.75 | V | 0.80-1.20 |
| Hardness (Tempered @ 520°C) | 54 HRC | Tensile Strength | ≥1200 MPa |
